48 - 56 Linear Shower Drain | ShowerLine Kit | QuickDrainUSA

48 - 56 Linear Shower Drains can be used for showers between 48″ and 56″. Buy the drain, channel covers, cover, sloping and waterproofing here. SL4856 Body Kit

Formerly part number PVC4856.

ShowerLine is a lower-cost way to achieve the same sleek, high-end look as the original Proline Drain, with a simplified ordering process using preconfigured shower pans and waterproofing kits.

The ShowerLine Drain system features a plastic drain body, and the shower pan pre-sloped panels are made from 100% repurposed materials.

Quickdrain, the US leader in linear drain systems, engineered ShowerLine to accommodate a wide variety of parameters and to make installation straightforward.

Features

• Adjustable trough extensions to always fit any size opening.
• Accommodates any topical waterproofing – sheet or liquid.
• Can be installed with a complete shower pan or a traditional mud bed.
• Height adjustable to accommodate different tile thicknesses.
• Linking drains together provides unlimited length.

These features and more make ShowerLine the go-to linear drain for installation professionals.

Specifications

• Drain body: 48″ long, made from PVC
• Clamping collar and extender: 16 and 26 gauge 304 stainless steel
• Fits finished opening: 48″ to 56″
• Trough: internally pitched, 1″ deep and 1″ wide
• Waste outlet: 2″ vertical only

Important sizing note

The 48 inch ShowerLine drain body cannot be cut, but it can be extended up to 56 inches using trough extensions.

Kit Includes

Kit contents when both the drain body and drain cover are purchased.

Drain Cover Information

• Width: 1-1/2″
• Thickness: 3/8″
• Material: 18 gauge 304 stainless steel
• Available lengths: 32″, 40″, 48″, 56″, 64″, 72″
• Custom sizes: Custom lengths are available from 10″ to 120″ (Cosmo) or 10″ to 70″ (Stream). Both styles are available in a brushed or polished stainless steel finish.
• Please note: Only Brushed Stainless, Polished Stainless, Brushed Gold and Matte Black drain covers are part of the quick ship program. All other drain cover finishes have limited stock and may have lead times up to 8 weeks.

Documents and Guides

Build a Complete ShowerLine System with Curb

Drain body & cover  +  ShowerLine pan kit  +  Waterproofing

Not sure which components you need? We will spec the full system for you.

Free Consultation | Start Now

Frequently Asked Questions

May I use a Tile In Drain Cover on a curbless shower if the drain is placed at the back wall?

Yes. You may use a Tile In Drain Cover as long as the drain body is not placed at the shower entrance.

If I order today, when will my system ship?

Orders typically ship in 2 business days. Need it faster? Expedited shipping is available at check-out.

Do I have to use the Quickdrain Membrane with the ShowerLine Drain?

No — ShowerLine Drain is compatible with all tile shower waterproofing methods.

•

  SHOWERLINE DRAIN Curbless Shower with Linear Shower Drain for Tile

  Finally an affordable curbless shower for tile is now possible...

•

  Affordable Linear Shower Drain on Concrete Slabs

  Showerline Drain by Quickdrain is an affordable & easy to inst...

•

  SHOWERLINEdrain Tub to Shower Conversion Kit

  Affordable tub to shower conversion video featuring the Afford...

•

  ShowerLine Linear Shower Drain Installation with Liquid Waterproofing

  Showerline is an affordable choice to create a beautiful linea...
