Hot Mop Shower Pan Collar for Quickdrain Systems

Quickdrain offers two ways to accomodate people who use the Hot Mop method to waterproof tile shower pans.  The HOTMD23-ABS and the HOTMD-CI.

If you're using HOTMOP to waterproof your shower and you're using either a Quickdrain SHOWERline or PROLINEdrain, you'll need this accessory to help ensure a successful job. These 2-part hot mop collars are for hot mop shower pan installations. Compatible with both ProLine and ShowerLine drains.

• The ABS clamping ring is for 2" and 3" waste lines.
• The cast iron clamping ring is for 2" waste lines only.

QuickDrain Hot Mop Collar | ABS or Cast Iron

Option 1) QUICKDRAIN ABS PLASTIC TWO PART CLAMPING RING | HOTMD23-ABS

The HOTMD23-ABS is designed for use in traditional shower pan installation. Using the countersunk holes, secure the flange base to the subfloor with an approved fastener. Shower pan drain shall have a solvent weld connection over 2" Sch. 40 DWV hub connection which conforms to ASTM D2665 (PVC) or D2661 (ABS). Strainer shall meet all necessary load and flow requirements for installations in shower areas.

Features:

• TWO PART CLAMPING RING made of ABS Plastic

• Least expensive clamping ring available

DIMENSIONS:

• [A]: Flange Diameter 2 3/8"

• [B]: Total Diameter 5 7/8"

• [C]: Barrel Diameter 2"-11.5 NPSM

• [D]: Total Height 2 7/8"



Option 2) QUICK DRAIN CAST IRON TWO PART CLAMPING RING | HOTMD23-CI

Features:

• Tongue and groove cast iron bolt down clamping ring

• Weep holes on both top and | bottom for secondary drainage

• Inside caulk unit can be used with gasket to make unit no caulk

DIMENSIONS:

• [A]: Total Diameter 6-½"

• [B]: Total Height 2-¼"

• [C]: Barrel Diameter 2-⅜"



NOTE: Often people who use hotmop waterproofing also use Leveling Brackets to keep the drain in place during installation.

SHOWERLINE LEVELING BRACKETS

• Click Here to View the ShowerLine PVC Leveling Brackets

PROLINE LEVELING BRACKETS

• Click Here to View the Short Leveling Brackets
• Click Here to View the Long Leveling Brackets

APPROVALS AND LISTINGS:

• Uniform Plumbing Code (UPC )

• National Plumbing Code of Canada

• International Plumbing Code (IPC )

• ASME A112.18.2-2015/CSA B125.2-15
