Aquatic Access pool lift | IGAT 180

$4,700.00
EZ Price: $4,599.00
ON SALE TODAY: $4,299.99
(You save $400.01 )
(1 review) Write a Review
SKU:
IGAT180
Shipping:
Free Shipping
Product:
Pool Lift
Weight Capacity:
400 Pounds
Origin:
Made in USA

Aquatic Access pool lift | IGAT 180

ADA Compliant - The Aquatic Access IGAT 180 Pool lift is one of the best selling pool lifts and works for most applications.

Model IGAT-180 is certified to meet the 2010 Standards for Accessible Design, which now a law in the United States.

Each Lift is Custom Made for Your Pool.

Pool Dimensional Worksheet

Are you replacing an existing Aquatic Access Pool Lift?

Often we receive calls from Aquatic Facilities from around the country who've enjoyed the use of their Aquatic Access pool lift for decades.  Yet, after years of reliable use, they are ready for a new lift.  For these installations, as long as the pool, water supply and lift requirements haven't changed, we can often process your order without a dimensional worksheet.  Simply place your order.  IN THE NOTES SECTION PROVIDE: Serial Number and/or the Installation Address.  EZ Able® will do the rest.  For all other customers, a dimensional worksheet is mandatory to have your custom pool lift manufactured.

Description | Aquatic Access IGAT 180

It is user-operable, and its seat height is easily adjustable to accommodate various wheelchair heights. The 180 degree clockwise turn allows the greatest access from the deck for the user and any assistants. Side-to-side transfers are easy, the footrest flips up and the mounting arm is under the seat. This allows for unobstructed transfer. The seat rotates forward when entering the pool, and backward when exiting the water. The standard seat has a right arm only, but a flip-up outer arm is available.

All components required for installation and operation are included in the price and ship with the lift, although many options and extras are available, including the new California Seating Package to meet the California Building Code for Pool Lifts. This unit is also available as a heavy-duty model with increased lifting capacity. Just let us know your needs when ordering.

Static pressure (measured at faucet or hose with no water flowing) is affected by variables in the material, length, diameter and rigidity of the water lines and hoses from the street to the lift, and by how many other faucets are open at the same time. Operating pressure requirement (measured while lifting) is not affected by these variables.

** Opposite facing (opposite turn) and heavy-duty units available (custom charges may apply).

Features:

  • In-Ground Automatic Turn 180°

  • Certified to meet the 2010 Standards for Accessible Design as well as the requirements of the ADA, ABA and CBC.

  • Powered by Water Pressure -- lifts up to 400 LB. at 55-65 PSI open flow water pressure

  • Custom Heavy-Duty Modification Available

  • No dangerous and expensive batteries required. Completely green to operate.

  • Standard Vertical Seat Travel - 42".

  • Portable (Lift Out and Put Away)

  • Each lift includes a seat belt.

  • Flip-Up Footrest Included.

  • California Seating Package Available to conform with California Building Code.

  • Can Be Padlocked in Deck Position.

  • Allows Independent Operation.

Standard Features:

  • Right arm on seat

  • no left arm

  • flip-up footrest

  • socket and socket cover

  • Seat Color: White or Blue

  • Clockwise rotation into pool, Counter-clockwise exiting pool

Available OPTIONS:

NOTE: Some Optional accessories may increase total weight and water pressure required to achieve rated load.

  • Counter-clockwise rotation into pool, Clockwise exiting pool

  • Flip-up Armrest(s)

  • Headrest

  • California Seating Package includes flip-up outer armrest accessory required by the California (and some other states) Building Codes.

Links:

Aquatic Access pool lift | IGAT 180

Aquatic Access offers a five-year warranty on all structural components and stainless steel parts, and a one-year warranty of valves, seals, and seat shells.

1 Review Hide Reviews Show Reviews

  • 5
    Life Changing Product

    Posted by Linda D. on 18th Jun 2018

    My whole life has changed since getting the pool lift. The pool I built three years ago and couldn’t get out of easily for the last two is back in my life! This pool lift is a piece of art. So simple and sturdy and reliable. The water does it all and it does it well. There’s no mess as the water used to raise and lower the lift goes directly into the pool. I have a few health problems including a back injury that makes walking and getting out of my pool pretty much impossible and this inactivity has exacerbated my conditions. I can feel it reversing as I get in my pool daily with confidence that I won’t get stuck. The lift just brings me out and at just the right speed. It truly is a mechanical piece of art.
