SquareDrain Shower Drain Universal Flange Adaptor

SquareDrain Shower Drain Universal Flange Adaptor

SquareDrain Shower Drain Universal Flange Adaptor is the first step to your square drain system.

The SquareDrain Shower Drain Universal Flange Adaptor is the part your square drain attaches to.

The QuickDrain large universal flange adaptor is compatible to QuickLiner sheet membrane and liquid applied membrane. Suitable for 4 in., 5 in. and 6 in. drain bodies. Elevate Your Shower Design with QuickDrain.

Key Features

• The small flange is compatible with 4 in. drain body assembly. The large flange is compatible with 5 in. or 6 in. drain body assemblies

• Universal flange adaptor features elongated bolt slots providing ultimate flexibility allowing the flange to adapt to numerous ABS, Cast Iron, and PVC drain bases

• Dual profile gasket seals to numerous drain bases and is compatible with pan liner or topical membrane

• Textured flange designed to bond topical sheet membrane with thinset

• Made of reinforced nylon molded in the USA and includes multiple countersunk locations to anchor to the subfloor

• Features multiple weep holes and weep guard accessory to promote proper wicking techniques

• Threaded adapter design allows for microadjustments- making installation of the SquareDrain drain body or traditional barrel assemblies quick and easy

• The interrupted threads make the assembly ready to test with our Oatey® 130 Series Tool-Free Test Plug

• Use the full kit for new construction and conversion kit for remodels.

• A conversion kit may be required when an approved ABS/PVC two-piece clamping collar drain is already installed.

Parts / Included

• Remodel Kit comes with (1) Small Reinforced Nylon Flange Adaptor, (1) Weep Protector, (4) Washers, (4) Hex Bolts

• New Construction PVC Kits come with (1) Small Reinforced Nylon Flange Adaptor, (1) PVC Drain Base, (1) Tool-Free Test Plug, (1) Weep Protector, (4) Washers, (4) Brass Inserts, (4) Hex Bolts

• New Construction ABS Kits come with (1) Small Reinforced Nylon Flange Adaptor, (1) ABS Drain Base, (4) Brass Inserts, (1) Tool-Free Test Plug, (1) Weep Protector, (4) Washers, (4) Hex Bolts

Recommended Flange Adaptor

Choose QuickDrain’s patented universal flange adaptor to complement the drain body. Large flange adaptor and accessories are compatible with 5 in. or 6 in. drain bodies, while the small flange adaptor and accessories are compatible with the 4 in. drain body.
